It's the metrics stupid!
Hubert Behaghel
hubert.behaghel@bskyb.com
Disclaimer
Business value? What do you mean?
Features with less bugs
Ready for future changes
That actually make customers happy
By not being slow
And because they let them achieve what they want
Efficiently
When is business value delivered?
[ ]When the code is checked in[ ]When the code is checked in and tests all pass[ ]When the code is checked in, tested and deployed[X]When it runs and the KPIs say so
Monitoring fact #1
We need to know what our code does when it runs.
What's Monitoring anyway?
The capability to continuously measure business value and code behaviours in production.
map ≠ territory
Do you know which code is faster
items.sort_by { |i| i.name }
items.sort { |a,b| a.name <=> b.name }
we don't know
def sort_by (&blk) sleep(100) # FIXME super(&blk) end
def sort (&blk) raise Exception.new("Oh Noes!") # :-) end
we need to know
measure
when is it too slow for your users?
measure
Justifying an investment in performance
\begin{equation} \frac{(KPI(today) + \Delta_{KPI}) * \Delta_{value / KPI\ unit}}{cost_{performance\ improvement}} = ROI\ (in\ days) \end{equation}why Google doesn't show you more results on each pages?
- customers asked for more
- Google experimented in 2006, increasing this number from 10 to 30
- triggered a drop by 20% of traffic and revenues.
- page load time from .4s to .9s
- Similar observation at Amazon: 100ms => 1% of revenue.
Monitoring fact #2
System performance affects success.
Mind the gap between what customers say they want and what they actually expect
measure
The forgotten Agile practice?
Agile
- "working software is the primary measure of progress"
- shared and always up-to-date view of the project
- focus on business value
- continuous deployment
Metrics and Monitoring
- only way to assess software is working
- shared and always up-to-date view of how the product is doing
- correlates business value and system performance
- only effective safety net to true continuous deployment
Monitoring fact #3
Monitoring is more important than testing.
because knowing the territory is more important that knowing the map.
Metrics, the ultimate enabler
Metrics help you making better decision
Metrics can be shared and communicated
Metrics enable experimentation / personalisation / ABtesting
Metrics enable performance management
Once you are able to measure, you should benchmark your solution
Performance testing
nominal latency/throughput under nominal load
aka
put your app on the treadmill and make it run at normal speed.
Load testing
…make it run fast and secure SLAs.
Stress testing
…make it run faster and faster up until it falls on the treadmill.
Notice the speed at which it happens.
Mitigate the consequences and automate recovery.
Resilience testing
…cut one of its legs while it's running and observe.
Again: mitigate the consequences and automate recovery.
Monitoring enables anti-fragile systems
- Resilience is actually not the real goal.
- Regenerative systems
- warrants another talk :-)
Increase your speed
Monitoring Fact #4
You can't own your code if you don't own its metrics.
Monitoring give you the ultimate power
Auto-rollback
Availability testing
- Chaos monkey
- Couple to your monitoring for total control.
Monitoring fact #5
Nothing can beat the level of control you get from your monitoring.
How to…
Instrument your code
holistic via runtime instrumentation
- monitoring == configuration
- 0 assumption
- all-in-one
- overhead: ~7% CPU
- proprietary software only: dynaTrace, New Relic, AppDynamics
bespoke via ad-hoc code
- pretty much the opposite benefits / drawbacks from the holistic approach.
- OSS powered: codahale/metrics, statsd, collectd, graphite
- Used by all the serious players: Yammer, dotCloud, Amazon …and LWS!
define a common language
Examples taken from CodaHale/metrics lib:
- Gauge
- the instantaneous value of something
metrics.gauge("orders") { orders.size }
- Counter
- incrementing/decrementing value
val counter = metrics.counter("connection") counter.inc() counter.dec()
- Meters
- average rate of events over a period of time
val requests = metrics.meter("requests", SECONDS) requests.mark()
- Histograms
- the statistical distribution of values in a stream
of data
val histogram = metrics.histogram("response-size") requests.update(response.completions.size)
- min, max, avg, std-dev: not good enough
- quantiles: p75, p90, p95, p99, p99.9…
- reservoir sampling
- Timer
- a histogram of durations and meter of calls
val timer = metrics.timer("requests", MILLISECONDS, SECONDS) timer.time { handle(req, resp) }
At ~300 req/sec, our p90 latency jumps from 13ms to 453ms.
Collect
Aggregate
Monitor and alarm
Watch and correlate
dashboards- graphing tool and search engine
1 service => ~50 metrics exported
Food for thoughts
Know what you want to measure
- Think. Learn.
- Be good at identifying what needs monitoring and with what kind of metrics.
Monitoring an API
Patterns and schemes
- Structure your metrics into schemes
- All REST endpoints that only support GET should capture similar metrics.
- When captured metrics are the same in 2 different endpoints, they
should be recorded with the same name.
- e.g. if "latency" and not "duration" or "elapsed" or …
Client-level
- if multiple clients, track the per client load on each API.
Expose an Is-It-Down monitor
- It is good practice to integrate your apps with the monitoring of your dependencies
- Live adaptation in e.g. your retry policy
- Show a message to the users to signal the degraded service level
Monitoring a website
UX
- latency, latency vs traffic
- journey success rate
Analytics
- collect arbitrary data to do segmentation (customer facetting?)
- behaviours / intents
Availability
- backbone & final mile testing
Usual application metrics
Don't divorce front-end and back-end monitoring
Monitoring a mobile experience
Impact of mobile network
Disconnected experience
Native vs Embedded Web Experience
Build and contribute to status.online.sky.com
- inspired by status.github.com
You are in charge
Metrics Everywhere!
Vote
Are you a slightly better engineer after this talk?
Appendices
Sources and Inspiration
- Metrics, Metrics everywhere by Coda Hale
- Application Monitoring Infrastructure at Yammer
- It's the Latency, Stupid
- Greg Linden / Marissa Mayer at Web 2.0
- Impact of web latency on conversion rates
Tools
- Etsy Statsd
- Statsite (statsd on steroid)
- Coda Hale metrics for Java
- Collectd
- Graphite
